M6 Solar Panels

Products include all black, bifacial, double glass, double glass bifacial, etc.; output power 340w-455w, double glass half-cut module has better power generation capacity, lower temperature coefficient, smaller shielding loss, and stronger mechanical load-bearing capacity.

Types of the M6 Solar Panels For Sale

M6 144cells 435-455w  Solar Panel

M6 144cells 435-455w Solar Panel

M6 144cells 435-455w  Solar PanelPDF DOWNLOAD
M6 144cells 435-455w  Solar Panel

The product adopts MBB design with more uniform crack stress distribution and higher reliability. Half cell reduces the heating of the module and improves the safety performance.

Dimension 2094×1038×35mm
Weight 23.5kg
No. of cells 144
Rated Maximum Power 455w
Maximum Efficiency 20.94%
Junction Box IP≥68, TÜV&UL
Maximum System Voltage DC1500
Operating Temperature -40℃ to 85℃
Cable&Connector 4mm2, EVO2 / EVO2 Compatible
M6 120cells 360-375w  Solar Panel

M6 120cells 360-375w Solar Panel

M6 120cells 360-375w  Solar PanelPDF DOWNLOAD
M6 120cells 360-375w  Solar Panel

The product adopts an MBB high-efficiency PERC cell combined with half cutting technology. It can meet the rising demand for high efficiency and diversification of residential roofs, small industrial and commercial roofs, and large ground power stations.

Dimension 1755×1038×35
Weight 20kg
No. of cells 120
Rated Maximum Power 375w
Maximum Efficiency 20.59%
Junction Box IP≥68, TÜV&UL
Maximum System Voltage DC1500
Operating Temperature -40℃ to 85℃
Cable&Connector 4mm2, EVO2 / EVO2 Compatible
M6 120cells 340-355w  Full Black Solar Panel

M6 120cells 340-355w Full Black Solar Panel

M6 120cells 340-355w  Full Black Solar PanelPDF DOWNLOAD
M6 120cells 340-355w  Full Black Solar Panel

The product adopts MBB design with a more uniform crack stress distribution and higher reliability. Half cell reduces the heating of the module and improves the safety performance. All black aesthetic BIPV, perfect fusion with architecture. Non-destructive cutting, greatly improved power and efficiency.

Dimension 1776×1052×35
Weight 20kg
No. of cells 120
Rated Maximum Power 355w
Maximum Efficiency 19.01%
Junction Box IP≥68, TÜV&UL
Maximum System Voltage DC1500
Operating Temperature -40℃ to 85℃
Cable&Connector 4mm2, EVO2 / EVO2 Compatible

M6 144cells 430-450w  Double Glasses & Bifacial Solar Panel

M6 144cells 430-450w Double Glasses & Bifacial Solar Panel

M6 144cells 430-450w  Double Glasses & Bifacial Solar PanelPDF DOWNLOAD
M6 144cells 430-450w  Double Glasses & Bifacial Solar Panel

The double-sided double glass half-cell module can not only absorb energy from the front of the module but also absorb reflected light and scattered light from the back. It has better power generation capacity, lower temperature coefficient, smaller shielding loss and stronger mechanical load. Half cell reduces the risk of hot spots for high power modules and shows better power generation performance and reliability in system applications.

Dimension 2094×1038×35mm
Weight 27kg
No. of cells 144
Rated Maximum Power 450w
Maximum Efficiency 20.71%
Junction Box IP≥68, TÜV&UL
Maximum System Voltage DC1500
Operating Temperature -40℃ to 85℃
Cable&Connector 4mm2, EVO2 / EVO2 Compatible
M6 120cells 355-370w  Bifacial Solar Panel

M6 120cells 355-370w Bifacial Solar Panel

M6 120cells 355-370w  Bifacial Solar PanelPDF DOWNLOAD
M6 120cells 355-370w  Bifacial Solar Panel

The product matches different installation conditions, takes into account high adaptability and high compatibility, with mature bracket and inverter solutions, and is specially designed for centralized ground power stations. Double-sided power generation technology can achieve a maximum of 30% backside gain.

Dimension 1755×1038×35
Weight 20kg
No. of cells 120
Rated Maximum Power 370w
Maximum Efficiency 20.32%
Junction Box IP≥68, TÜV&UL
Maximum System Voltage DC1500
Operating Temperature -40℃ to 85℃
Cable&Connector 4mm2, EVO2 / EVO2 Compatible

M6 144cells 425-445w  Bifacial Solar Panel

M6 144cells 425-445w Bifacial Solar Panel

M6 144cells 425-445w  Bifacial Solar PanelPDF DOWNLOAD
M6 144cells 425-445w  Bifacial Solar Panel

The product matches different installation conditions, takes into account high adaptability and high compatibility, with mature bracket and inverter solutions, and is specially designed for centralized ground power stations. Double-sided power generation technology can achieve a maximum of 30% backside gain.

Dimension 2094×1038×35
Weight 23.5kg
No. of cells 144
Rated Maximum Power 445w
Maximum Efficiency 20.48%
Junction Box IP≥68, TÜV&UL
Maximum System Voltage DC1500
Operating Temperature -40℃ to 85℃
Cable&Connector 4mm2, EVO2 / EVO2 Compatible
