G1 Solar Panels

Sunrise G1 solar panel, using 158.75mm monocrystalline cells, product customization includes full black double-sided double-glass, power grade is divided into 325-345w, 390-415w two grades, the product has the characteristics of anti-hot spot, better power generation performance and reliability.

Monocrystalline 330-415w high-efficiency series

This series of modules, with two types of 120 and 144 pieces, are precision encapsulated with multi-grid half-sheet technology, with a 25-year product line warranty, 12-year product material and process warranty, and customizable line length, and the products are certified by TUV/BIS/INMETRO/PV CYCLE/CE/CQC/CSI/ISO.

Monocrystalline 325-410w Jellyfish Series

This series of modules, with two versions of 120,144, unique double-sided power generation technology, up to 30% power generation gain, monocrystalline multi-main gate half-sheet technology, anti-PID guarantee, front static load 5400pa, back static load 2400pa, with 25 years product line warranty, 12 years product material and process warranty, line length can be customized, products through TUV/BIS/ INMETRO/PV CYCLE/CE/CQC/CSI/ISO certifications.

Types of the G1 Solar Panels For Sale

G1 120cells 330-345w Solar Panel

G1 120cells 330-345w Solar Panel

G1 120cells 330-345w Solar PanelPDF DOWNLOAD

G1 120cells 330-345w Solar Panel

The product uses multi-main gate high-efficiency PERC batteries to combine battery semi-technical, effectively reducing monovato system costs; while battery semi-technical effectively reduces the risk of hot spots in high power components, exhibiting better power generation performance and reliability in system applications.

Dimension 1684×1002×35mm
Weight 19.1kg
No. of cells 120
Rated Maximum Power 345w
Maximum Efficiency 20.45%
Junction Box IP≥68, TÜV&UL
Maximum System Voltage DC1000/DC1500
Operating Temperature -40℃ to 85℃
Cable&Connector 4mm2, EVO2 / EVO2 Compatible
G1 144cells 395-415w Solar Panel

G1 144cells 395-415w Solar Panel

G1 144cells 395-415w Solar PanelPDF DOWNLOAD

G1 144cells 395-415w Solar Panel

MBB and PERC cell tech are used on this product, combined with half cell technology, effectively reduce the cost of the single-watt system; Can respond to the residential roof, small industrial and commercial roof, large ground power station constantly rising high efficiency and diversified needs.

Dimension 2008×1002×35mm
Weight 22.4kg
No. of cells 144
Rated Maximum Power 415w
Maximum Efficiency 20.63%
Junction Box IP≥68, TÜV&UL
Maximum System Voltage DC1000/DC1500
Operating Temperature -40℃ to 85℃
Cable&Connector 4mm2, EVO2 / EVO2 Compatible
G1 120cells 325-340w Bifacial Solar Panel

G1 120cells 325-340w Bifacial Solar Panel

G1 120cells 325-340w Bifacial Solar PanelPDF DOWNLOAD

G1 120cells 325-340w Bifacial Solar Panel

This product matches different installation conditions, takes into account high adaptability and high compatibility, with mature support and inverter solutions, and is specially designed for centralized ground power stations. Bifacial technology could achieve a maximum of 30% efficiency power from the backside.

Dimension 1684×1002×35
Weight 19.1kg
No. of cells 120
Rated Maximum Power 340w
Maximum Efficiency 20.15%
Junction Box IP≥68, TÜV&UL
Maximum System Voltage DC1000/DC1500
Operating Temperature -40℃ to 85℃
Cable&Connector 4mm2, EVO2 / EVO2 Compatibility
G1 144cells 390-410w Bifacial Solar Panel

G1 144cells 390-410w Bifacial Solar Panel

G1 144cells 390-410w Bifacial Solar PanelPDF DOWNLOAD

G1 144cells 390-410w Bifacial Solar Panel

This product matches different installation conditions, takes into account high adaptability and high compatibility, with mature support and inverter solutions, and is specially designed for centralized ground power stations. Bifacial technology could achieve a maximum of 30% efficiency power from the backside.

Dimension 2008×1002×35mm
Weight 22.4kg
No. of cells 144
Rated Maximum Power 410w
Maximum Efficiency 20.38%
Junction Box IP≥68, TÜV&UL
Maximum System Voltage DC1000/DC1500
Operating Temperature -40℃ to 85℃
Cable&Connector 4mm2, EVO2 / EVO2 Compatible
